Model | YSSG-1650 |
Max printing area(mm) | 2400*1450 |
Max cardboard size(mm) | 2400*1650 |
Min cardboard size(mm) | 600 |
Max printing speed(pages/min) | 60 |
Printed board thickness(mm) | 7-11 |
Host power | 5.5 |
Dimensions(mm) | 5630*2350*2020 |
Weight(kg) | 9500 |
Model | YSSG-1850 |
Max printing area(mm) | 2400*1650 |
Max cardboard size(mm) | 2400*1850 |
Min cardboard size(mm) | 600 |
Max printing speed(pages/min) | 60 |
Printed board thickness(mm) | 7-11 |
Host power | 5.5 |
Dimensions(mm) | 5800*2450*2100 |
Weight(kg) | 10500 |
Model | YSSG-2000 |
Max printing area(mm) | 2400*1850 |
Max cardboard size(mm) | 2400*2050 |
Min cardboard size(mm) | 600 |
Max printing speed(pages/min) | 60 |
Printed board thickness(mm) | 7-11 |
Host power | 7.5 |
Dimensions(mm) | 5800*2850*2100 |
Weight(kg) | 13000 |
Model | YSSG-3000 |
Max printing area(mm) | 3000*1800 |
Max cardboard size(mm) | 3000*2050 |
Min cardboard size(mm) | 600 |
Max printing speed(pages/min) | 50 |
Printed board thickness(mm) | 7-11 |
Host power | 11.5 |
Dimensions(mm) | 7200*2800*2240 |
Weight(kg) | 18000 |
Besides the corrugated carton making equipment, Jiufeng company also provide rotary drum large format flexographic printing machine for printing cartons, and as we provide complete corrugated cardboard box machine line, including corrugated cardboard printer, slotter cutter, cardboard folder and gluer with plenty of experience since 1996, we are sure to offer customers high quality corrugated carton equipment and corrugated cardboard solutions for customers.
